Portable Oscilloscope 5 Channel 1MHz Bandwidth 3MHz Sampling Rate USB Type C WiFi Handheld Oscilloscope

Feature: 1. 5 Channels: The oscilloscope has 5 independent channels, enhancing the multifunctionality of the signal, allowing synchronous data recording of multiple signal sources, catering to the needs of professionals and advanced learners. 2. High Sampling Rate: The oscilloscope supports high resolution waveforms with up to 3MHz sampling rate in three channels, suitable for precise measurements in various projects. 3. Portable Design: The oscilloscope features 4.3 inch screen, 480x272 resolution, bright colors, and high contrast. Ultra thin design, convenient to carry, space saving design, very suitable for mobile applications. 4. Data Display: Frequency, period, peak to peak voltage (Vp p), maximum value, minimum value, average value, root mean square value (RMS), amplitude, duty cycle, pulse width. 5. Multi Platform Compatibility: The oscilloscope can seamlessly connect to PC software or mobile APPs through USB Type C or WiFi, providing real time control and data analysis. 6. Rechargeable Battery: The portable oscilloscope is equipped with 2000mAh detachable battery, with a battery life of about 3 hours. Suitable for tasks that require reliable handheld operation. Specification: Item Type: Portable Oscilloscope Material: ABS Screen: 4.3 Inch IPS Display Screen, Resolution 480x272 Channels: 5 Bandwidth: 1MHz Maximum Sampling Rate: 3 Channels 3MHz, 4 5 Channels 1.5MHz Input Impedance: 1M Ohm 20pF Input Mode: AC DC Maximum Measurement Voltage: + 10V (X10: + 100V) Maximum Peak to Peak Voltage: 20V (X10: 200V) Voltage Range: PC Software Mobile APP: 2mV div to 2V div Screen: 4mV div to 4V div Time Base Range: PC Software Mobile APP: 1µs div to 10800s div Screen: 1µs div to 4s div Record Depth: 8mx5 Channels, Up to 90 Hours Waveform Modes: YT, XY, ROLL Vertical Resolution: 8 Bits Trigger Type: Rising Edges, Falling Edges Data Display: Frequency, Period, Peak to Peak Voltage (Vp p), Maximum, Minimum, Average, RMS, Amplitude, Duty Cycle, Pulse Width Language: English, Chinese, Portuguese, Spanish Port Type: USB Type C Current Consumption: <2A Battery: 1 x 2000mAh Rechargeable Li Battery (Built in) Signal Output Frequency: 1kHz Size: Approx. 150x100x32mm 5.91x3.94x1.26in. Package List: 1 x Portable Oscilloscope 1 x USB Cable 1 x Oscilloscope Instruction Manual Note:
